FC / PC Female to Female Fiber Optic Coupler Flange Attenuator 5dB Single Mode

Brand Name : YINGDA

Model Number : ATTN-FCS-01-R05

Certification : ISO

Place of Origin : china

MOQ : 100PCS

Price : Negotiable

Payment Terms : T/T or western Union

Supply Ability : 50,000pcs per month

Delivery Time : 3-5 days

Packaging Details : 1 pc / plastic bag

Attenuation : 5 dB

wavelength range : 1260-16500nm

test wavelength : 1310nm, 1550nm

material : metal zinc alloy or copper

Additional loss : 0.1dB

Working temperature : -40～+85 (℃)

Fiber optic type : single mode

standard : GR910, IEC

product name : fiber network adapter,fiber optic coupling,media converter adapter,microwave attenuators,high power attenuators,fixed coaxial attenuator,hybrid attenuator

Contact Now

FC / PC Female to Female Attenuator, Fiber Optic Coupler Attenuator 5dB

Optical adapter flange type attenuator is used for attenuation of optical power device, which is

mainly used for index measurement, short distance communication system fiber signal attenuation

and test and other occasions.

Optical fiber attenuator as a kind of optical passive device, debug the optical power, debug optical

instrument calibration, and use for optical signal attenuation. It is made of attenuation optical fiber

which mix with metal ions, so it can adjust the light power to the required level.

Specification

  1. Wavelength: 1260~1620nm
  2. Initial Insertion Loss < 1.0dB
  3. Attenuation Range:1dB-60dB
  4. Fiber: SMF-28e
  5. Cable option: bare fiber/0.9mm loose tube/2mm cable
  6. Connector Option: FC/SC/LC.etc.

Order information

Fibery type

Cable diameter

Fiber length

Connector type

A=SM

S=customer specify

3=3mm fiber

2=2mm fiber

09=900 loose tube

S=customer specify

01=1M

02=2M

S=customer specify

0=None

1=FC/PC

2=FC/APC

3=SC/APC

4=SC/PC

5=ST

6=LC

7=customer specify

FC / PC Female to Female Fiber Optic Coupler Flange Attenuator 5dB Single Mode
